Teradek Serv Micro
Teradek Serv Micro is a compact wireless video encoder and streaming device designed for professional video production. It supports video streaming up to 1080p30 via Wi-Fi, Ethernet, or an optional cellular connection, with HDMI input/output, SD card recording, and support for the VUER app for local monitoring and sharing.
- Video streaming up to 1080p30
- HDMI 2.0 input and output
- Dual-band Wi-Fi 6, 2.4/5GHz
- Ethernet connectivity
- SD/SDHC/SDXC card recording
- Streaming to up to 10 devices
- 256-bit AES encryption
- Bonding of up to 7 network connections
- 3.5mm microphone/line input
- Sony L-Series battery mount
- Power consumption: 6W
- Dimensions: 105 × 75 × 28 mm
- Weight: approximately 190 g
Wirelessly stream up to 1080p30 video to 10 devices via Wi-Fi using the compact Serv Micro from Teradek. Like others in the Serv video transmitter line, the Serv Micro is ideal for sharing your footage on set from production to post. This allows your videographers, editors, and producers to work in close collaboration.
The Serv Micro inputs video via HDMI, inputs audio via 3.5mm mic/line input, and streams video via Wi-Fi, Ethernet, or via a separately available USB cellular modem. It is also capable of recording the monitored stream to an SD card. A free iOS and Android compatible app allows for local sharing and messaging using the Teradek VUER app, and doesn’t require an internet connection. The Serv Micro is equipped with Teradek Core compatibility for sharing globally using various devices. It also supports 256-bit encryption to ensure secure sharing. It also supports bonding on up to 7 networks, via Ethernet, Wi-Fi, and cellular.
On-Set Streaming
- Connect the crew from anywhere on set with live camera feeds streamed to 10 devices or 20 when connected to a local network via the free VUER app
- Easy, customizable app monitoring tools
- True image fidelity with critical resolution and color-accuracy with low delay
- Distribute secure, 256-bit encrypted streams
- Display up to four camera feeds at once
Off-Set Streaming
- Share live camera feeds up to 1080p30 with remote stakeholders via the cloud to computers, TVs, smartphones, or tablets via Core
- Collaborate live via integrated messaging and voice chat
Postproduction Streaming
- Send up to 1080p30 video in real time to editors, colorists, VFX teams, directors, and other remote collaborators with Core
- Send streams through the cloud to anymore in your production
Bonding
Simultaneous bonding over up to 7 networks:
- Ethernet
- Wi-Fi
- USB cellular modem
- Up to 4 smartphones (iOS or Android)
| Teradek Serv Micro | |
| 2 x Antenna | |
| Mini-HDMI Type C to HDMI Type A | |
| Ethernet Cable | |
| Shoe Mount Adapter | |
| Carrying Bag |
